Build an AI Agent Web App with LangGraph and CopilotKit

Most AI agent tutorials stop at the backend. You get a LangGraph workflow or a CrewAI crew, you run it in a terminal, and the output is a blob of text. The hard part they skip is wiring that agent into an actual application where users can interact with it, see intermediate progress, and control its behavior through a UI.

This tutorial builds the full stack. A Python LangGraph agent handles research - breaking queries into sub-searches, fetching web content via Tavily, and generating a research draft. A Next.js frontend renders the progress in real time, lets users add their own resources, and provides a chat panel for steering the agent. CopilotKit connects the two, streaming intermediate state from the agent graph into React components.

By the end, you will have a research assistant where you type a question, watch it search the web, and get a formatted draft you can edit.

Prerequisites

Python 3.12+ for the LangGraph agent
Node.js 18+ for the Next.js frontend
OpenAI API key for LLM inference
Tavily API key for web search (free tier available at tavily.com)

Project Structure

The application runs as two independent processes:

project/
  ui/              # Next.js frontend
    app/
      api/copilotkit/route.ts
      page.tsx
    components/
      ResearchCanvas.tsx
      Progress.tsx
      ModelSelector.tsx
      Resources.tsx
  agent/           # Python LangGraph backend
    agent.py       # Graph definition
    chat.py        # Chat node with tool binding
    search.py      # Tavily search node
    download.py    # Resource download node
    delete.py      # Resource deletion node
    state.py       # Agent state types
    model.py       # Model selection
    demo.py        # FastAPI server

The UI deploys anywhere you can run Next.js. The agent deploys anywhere you can run Python - a separate server, a Docker container, or LangGraph Cloud. They communicate over HTTP through CopilotKit's co-agent protocol.

Setting Up the Agent

State Definition

Every LangGraph application starts with state. The state object flows through every node in the graph, accumulating data as the agent works:

from dataclasses import dataclass, field
from typing import List, Optional
from langchain_core.messages import BaseMessage

@dataclass
class Resource:
    url: str
    title: str = ""
    description: str = ""

@dataclass
class LogEntry:
    message: str
    done: bool = False

@dataclass
class AgentState:
    model: str = "openai"
    research_question: str = ""
    report: str = ""
    resources: List[Resource] = field(default_factory=list)
    logs: List[LogEntry] = field(default_factory=list)
    messages: List[BaseMessage] = field(default_factory=list)

The resources list holds URLs the agent has discovered or the user has manually added. The logs list tracks progress for the UI. The messages list maintains the conversation history. All of this flows through the graph and streams to the frontend.

Building the Graph

The graph defines how nodes connect. Each node is a function that receives the current state and returns updates:

from langgraph.graph import StateGraph, END
from langgraph.checkpoint.memory import MemorySaver

from state import AgentState
from chat import chat_node
from search import search_node
from download import download_node
from delete import perform_delete_node

def route_after_chat(state: AgentState) -> str:
    """Decide where to go after the chat node based on tool calls."""
    messages = state.messages
    last_message = messages[-1] if messages else None

    if not last_message or not hasattr(last_message, "tool_calls"):
        return END

    for tool_call in last_message.tool_calls:
        if tool_call["name"] == "search":
            return "search_node"
        if tool_call["name"] == "delete_resource":
            return "delete_node"

    return END

# Build the graph
workflow = StateGraph(AgentState)

workflow.add_node("download", download_node)
workflow.add_node("chat", chat_node)
workflow.add_node("search_node", search_node)
workflow.add_node("delete_node", perform_delete_node)

# Entry point: download any initial resources
workflow.set_entry_point("download")

# After downloading, go to chat
workflow.add_edge("download", "chat")

# After chat, conditionally route based on tool calls
workflow.add_conditional_edges("chat", route_after_chat, {
    "search_node": "search_node",
    "delete_node": "delete_node",
    END: END,
})

# Search and delete loop back to chat
workflow.add_edge("search_node", "chat")
workflow.add_edge("delete_node", "chat")

memory = MemorySaver()
graph = workflow.compile(checkpointer=memory)

The flow works like this:

Download - fetch content from any pre-loaded resources
Chat - the LLM evaluates the current state, decides what to do
Route - if the LLM called a tool, route to that node. Otherwise, end.
Search/Delete - execute the tool, then loop back to Chat

The MemorySaver checkpointer gives the graph persistence. If the user sends a follow-up message, the graph resumes from the last checkpoint instead of starting over.

The Chat Node

The chat node is where the LLM reasoning happens. It receives the full state, constructs a prompt with the research question and resources, and decides whether to respond directly or invoke a tool:

from langchain_openai import ChatOpenAI
from langchain_core.messages import SystemMessage, HumanMessage

def chat_node(state: AgentState, config: dict) -> dict:
    model_name = state.model or "openai"
    research_question = state.research_question
    report = state.report
    resources = state.resources

    # Format resources for the prompt
    resource_context = ""
    for r in resources:
        if r.description:
            resource_context += f"\n- {r.title}: {r.description[:2000]}"

    # Initialize the model with tools bound
    llm = ChatOpenAI(model="gpt-4o-mini", temperature=0)
    llm_with_tools = llm.bind_tools([search_tool, delete_tool, write_report_tool])

    system_prompt = f"""You are a research assistant. Help the user research their topic.

Research question: {research_question}
Current report draft: {report}
Available resources:
{resource_context}

Use the search tool to find relevant information.
Use the write_report tool to update the research draft.
Use the delete_resource tool if the user wants to remove a resource."""

    messages = [SystemMessage(content=system_prompt)] + state.messages

    response = llm_with_tools.invoke(messages)

    # Check for write_report tool call
    if response.tool_calls:
        for tc in response.tool_calls:
            if tc["name"] == "write_report":
                return {
                    "report": tc["args"]["report"],
                    "messages": [response],
                }

    return {"messages": [response]}

The key pattern here is tool binding. The LLM receives a list of available tools and decides based on context which ones to call. If the user's question needs more information, it calls search. If the user asks to remove a resource, it calls delete_resource. If it has enough context to write, it calls write_report.

The Search Node

The search node uses Tavily to find relevant web content. It breaks the query into sub-searches, fetches results, and extracts the most relevant resources:

from tavily import TavilyClient
import os

tavily = TavilyClient(api_key=os.environ["TAVILY_API_KEY"])

def search_node(state: AgentState, config: dict) -> dict:
    messages = state.messages
    last_message = messages[-1]

    search_queries = []
    for tool_call in last_message.tool_calls:
        if tool_call["name"] == "search":
            search_queries.append(tool_call["args"]["query"])

    logs = []
    all_results = []

    for query in search_queries:
        logs.append({"message": f"Searching: {query}", "done": False})

        # Emit intermediate state for the UI
        config["callbacks"][0].on_custom_event(
            "state_update",
            {"logs": logs}
        )

        response = tavily.search(query, max_results=5)
        all_results.extend(response.get("results", []))

        logs[-1]["done"] = True

    # Use LLM to extract the 3-5 most relevant resources
    llm = ChatOpenAI(model="gpt-4o-mini", temperature=0)

    extraction_prompt = f"""Extract the 3-5 most relevant resources from these search results.
Return them as a list with URL, title, and a brief description.

Search results:
{all_results}"""

    extraction = llm.invoke([HumanMessage(content=extraction_prompt)])

    # Process extracted resources
    new_resources = parse_resources(extraction.content)

    return {
        "resources": state.resources + new_resources,
        "logs": [],
    }

The intermediate state emission is what makes this feel responsive. Instead of waiting for all searches to complete, each search logs its progress immediately. The UI picks this up and shows "Searching: quantum computing applications" with a spinner, then marks it done when results arrive.

The Download Node

When the user adds a URL manually, the download node fetches the page content:

import requests
from html2text import HTML2Text

h2t = HTML2Text()
h2t.ignore_links = False
h2t.ignore_images = True

def download_resource(url: str) -> str:
    headers = {"User-Agent": "Mozilla/5.0 (compatible; ResearchBot/1.0)"}
    response = requests.get(url, headers=headers, timeout=10)
    return h2t.handle(response.text)

def download_node(state: AgentState, config: dict) -> dict:
    resources = state.resources
    logs = []

    for i, resource in enumerate(resources):
        if not resource.description:
            logs.append({"message": f"Downloading: {resource.url}", "done": False})

            config["callbacks"][0].on_custom_event(
                "state_update",
                {"logs": logs}
            )

            content = download_resource(resource.url)
            resources[i].description = content[:5000]

            logs[-1]["done"] = True

    return {"resources": resources, "logs": []}

Only resources without a description get downloaded. This prevents re-downloading on every graph execution.

Get the weekly deep dive

Tutorials on Claude Code, AI agents, and dev tools - delivered free every week.

Setting Up the Frontend

The CopilotKit Route

CopilotKit needs an API route to proxy requests between the frontend and the agent:

import { CopilotRuntime, OpenAIAdapter } from "@copilotkit/runtime";
import OpenAI from "openai";

const openai = new OpenAI();
const adapter = new OpenAIAdapter({ openai });

export async function POST(req: Request) {
  const runtime = new CopilotRuntime({
    remoteActions: [
      {
        url: process.env.REMOTE_ACTION_URL || "http://localhost:8000",
      },
    ],
  });

  const { handleRequest } = runtime;
  return handleRequest(req, adapter);
}

The REMOTE_ACTION_URL points to wherever your Python agent is running. For local development, that is http://localhost:8000. In production, it is whatever server or cloud service hosts your agent.

The Main Page

The page wraps the application in CopilotKit providers and renders the research canvas alongside the chat panel:

"use client";
import { CopilotKit } from "@copilotkit/react-core";
import { CopilotChat } from "@copilotkit/react-ui";
import { ResearchCanvas } from "@/components/ResearchCanvas";

export default function Page() {
  return (
    <CopilotKit runtimeUrl="/api/copilotkit">
      <div className="flex h-screen">
        <div className="flex-1 overflow-auto">
          <ResearchCanvas />
        </div>
        <div className="w-96 border-l">
          <CopilotChat
            labels={{ title: "Research Assistant" }}
            instructions="Help the user research their topic. Use search to find information and write a research draft."
          />
        </div>
      </div>
    </CopilotKit>
  );
}

The layout is split: the research canvas takes the main area, and the CopilotKit chat panel sits in a sidebar. Everything the user types in the chat panel goes to the LangGraph agent. Everything the agent does streams back to the canvas.

The Research Canvas

This is where agent state becomes visible. The canvas reads the co-agent state and renders resources, progress logs, and the research draft:

"use client";
import { useCopilotAction, useCoAgentState } from "@copilotkit/react-core";
import { useState } from "react";

interface AgentState {
  model: string;
  research_question: string;
  report: string;
  resources: Array<{
    url: string;
    title: string;
    description: string;
  }>;
  logs: Array<{
    message: string;
    done: boolean;
  }>;
}

export function ResearchCanvas() {
  const { state, setState } = useCoAgentState<AgentState>({
    name: "research_agent",
    initialState: {
      model: "openai",
      research_question: "",
      report: "",
      resources: [],
      logs: [],
    },
  });

  const [newResourceUrl, setNewResourceUrl] = useState("");

  // Handle resource deletion with user confirmation
  useCopilotAction({
    name: "delete_resource",
    description: "Remove a resource from the research context",
    handler: async ({ url }) => {
      setState((prev) => ({
        ...prev,
        resources: prev.resources.filter((r) => r.url !== url),
      }));
    },
  });

  function addResource() {
    if (!newResourceUrl.trim()) return;

    setState((prev) => ({
      ...prev,
      resources: [
        ...prev.resources,
        { url: newResourceUrl, title: "", description: "" },
      ],
    }));
    setNewResourceUrl("");
  }

  return (
    <div className="p-8 max-w-4xl mx-auto">
      <h1 className="text-2xl font-bold mb-6">Research Canvas</h1>

      {/* Research question input */}
      <input
        value={state.research_question}
        onChange={(e) =>
          setState((prev) => ({ ...prev, research_question: e.target.value }))
        }
        placeholder="What would you like to research?"
        className="w-full border rounded px-4 py-3 mb-6 text-lg"
      />

      {/* Progress logs */}
      {state.logs.length > 0 && (
        <div className="mb-6 space-y-2">
          {state.logs.map((log, i) => (
            <div key={i} className="flex items-center gap-2 text-sm">
              <span className={log.done ? "text-green-600" : "text-yellow-600"}>
                {log.done ? "Done" : "Working..."}
              </span>
              <span>{log.message}</span>
            </div>
          ))}
        </div>
      )}

      {/* Resources */}
      <div className="mb-6">
        <h2 className="text-lg font-semibold mb-3">Resources</h2>
        <div className="flex gap-2 mb-3">
          <input
            value={newResourceUrl}
            onChange={(e) => setNewResourceUrl(e.target.value)}
            placeholder="https://example.com/article"
            className="flex-1 border rounded px-3 py-2"
          />
          <button
            onClick={addResource}
            className="px-4 py-2 bg-black text-white rounded"
          >
            Add
          </button>
        </div>
        <div className="grid grid-cols-2 gap-3">
          {state.resources.map((resource, i) => (
            <div key={i} className="border rounded p-3">
              <p className="font-medium truncate">
                {resource.title || resource.url}
              </p>
              <p className="text-sm text-gray-500 truncate">{resource.url}</p>
            </div>
          ))}
        </div>
      </div>

      {/* Research draft */}
      <div>
        <h2 className="text-lg font-semibold mb-3">Draft</h2>
        <textarea
          value={state.report}
          onChange={(e) =>
            setState((prev) => ({ ...prev, report: e.target.value }))
          }
          className="w-full border rounded p-4 min-h-[300px] font-mono text-sm"
          placeholder="The research draft will appear here..."
        />
      </div>
    </div>
  );
}

The useCoAgentState hook is what makes this work. It creates a two-way binding between React state and the LangGraph agent state. When the agent updates resources or report, those changes flow into the React component. When the user edits the research question or adds a resource, those changes flow back to the agent.

Running the Application

Start both processes:

# Terminal 1: Start the Python agent
cd agent
poetry install
poetry run demo
# Runs on http://localhost:8000

# Terminal 2: Start the Next.js frontend
cd ui
pnpm install
pnpm dev
# Runs on http://localhost:3000

Open http://localhost:3000. Type a research question. Use the chat panel to say "search for recent developments in quantum computing" or whatever your topic is. Watch the logs update as the agent searches, see resources populate, and read the draft as it generates.

Key Patterns to Take Away

Intermediate state streaming is what separates this from a basic chatbot. Users see search progress, resource discovery, and draft generation in real time. The logs array and CopilotKit's state streaming make this possible without custom WebSocket code.

Two-way state binding means the user is not passive. They can add resources, edit the draft, change the model, and refine the research question. The agent respects these changes on its next turn.

Conditional routing in the graph lets the LLM decide the workflow at runtime. The same chat node can trigger a search, delete a resource, or write a report depending on what the user asks. You define the possible paths; the model picks which one to take.

Separation of concerns keeps each piece manageable. The graph nodes are small Python functions. The React components render state. CopilotKit handles the communication protocol. You can upgrade any layer independently.

This architecture scales to more complex agents. Add more tools to the chat node, more nodes to the graph, more components to the canvas. The pattern of state flowing through a graph and streaming into a UI stays the same regardless of how many nodes or tools you add.
